Gas Discharge
SERIES SURGE PROTECTOR(SURGE ARRESTER)
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.10
Model:
BLQ-GD-3GDBC
V.S.W.R:
≤ 1.20
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-3000MHz
Bulkhead:
Yes
Peak Power:
500
W (MAX)
Connector:
7/16(DIN)-M/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
80
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.10
Model:
BLQ-GD-3GDB
V.S.W.R:
≤ 1.20
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-3000MHz
Bulkhead:
Yes
Peak Power:
500
W (MAX)
Connector:
7/16(DIN)-M/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
80
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.20
Model:
BLQ-GD-2.5GNBS
V.S.W.R:
≤ 1.15
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-M/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
85
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.20
Model:
BLQ-GD-2.5GNBD
V.S.W.R:
≤ 1.15
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-F/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
85
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.20
Model:
BLQ-GD-2.5GNBR
V.S.W.R:
≤ 1.15
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-M/F
Discharge Capacity:
20
Temperature:
-40
℃
- +
85
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.20
Model:
BLQ-GD-6GNBR
V.S.W.R:
≤ 1.40
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-6000MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-M/F
Discharge Capacity:
10KA/20KA
Temperature:
-40
℃
- +
85
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.20
Model:
BLQ-GD-6GNFBR
V.S.W.R:
≤ 1.40
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-6000MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-F/F
Discharge Capacity:
10KA/20KA
Temperature:
-40
℃
- +
85
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.20
Model:
BLQ-GD-2.5GNBZ
V.S.W.R:
≤ 1.15
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-M/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
85
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.20
Model:
BLQ-GD-2.5GTBC
V.S.W.R:
≤ 1.15
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
TNC-M/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
85
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.20
Model:
BLQ-GD-3GSBC
V.S.W.R:
≤ 1.15
Class:
Gas Discharge
Impedance:
50 Ω
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
SMA-M/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
85
℃
Item Name:
Gas Discharge Protector
Insertion loss:
≤
0.20
Model:
BLQ-GD-2.5GFA
V.S.W.R:
≤ 1.20
Class:
Gas Discharge
Impedance:
75 Ω
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200W
Connector:
F-M/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
80
℃
Item Name:
Hybrid Quarter Wave
Insertion loss:
≤
0.20
Model:
BLQ-HGD-722GDB
V.S.W.R:
≤ 1.20
Class:
1/4λ
+Gas Discharge
Impedance:
50 Ω
Frequency:
698-2200MHz
Bulkhead:
Yes
Discharge Voltage:
90/250/350/600V
Connector:
7/16(DIN)-M/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
80
℃
Item Name:
Hybrid Quarter Wave
Insertion loss:
≤
0.20
Model:
BLQ-HGD-825GDB
V.S.W.R:
≤ 1.20
Class:
1/4λ
+Gas Discharge
Impedance:
50 Ω
Frequency:
800-2500MHz
Bulkhead:
Yes
Discharge Voltage:
90/350V
Connector:
7/16(DIN)-F/F
Discharge Capacity:
20KA
Temperature:
-40
℃
- +
80
℃
Item Name:
Hybrid Quarter Wave
Insertion loss:
≤
0.20
Model:
BLQ-HGD-727GD
V.S.W.R:
≤ 1.20
Class:
1/4λ
+Gas Discharge
Impedance:
50 Ω
Frequency:
698-2700MHz
Bulkhead:
Yes
Discharge Voltage:
350V
Connector:
7/16(DIN)-F/F
Discharge Capacity:
30KA
Temperature:
-40
℃
- +
80
℃
Item Name:
Gas Discharge Tube
△Vdc(%)
± 20%
Model:
H2R-VXX
I(KA
@8/20μS
5
Class:
Gas Discharge
Tube
I(A
@10/1000μS)
100
Vdc(V@100v/s)
90/150/230/350/600
Cp(pF@1MHz)
≤ 1.5
Gas Discharge
SERIES SURGE PROTECTOR(SURGE ARRESTER)
